| General Description |
CD Player, DAC, Pre-Amp
with Integrated amplifier |
| Key Technology & Features |
DSD (up to DSD256 Compatible) / Bluetooth (aptX)
DTS Play-Fi Technology |
| Audio File Formats |
ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, AACHE,
AAC+, DSD64, DSD128, DSD256 |
| D/A Converter |
ESS ES9018 32bit DAC |
| USB Input |
USB B (PC / MAC) |
| Digital Audio Inputs |
2 x Optical TOSlink, 2 x RCA (DIG1, DIG2) |
| Digital Audio Outputs |
1 x Optical TOSlink, 1 x RCA (DIG) |
| Analogue Inputs |
2 x RCA (AUX1, AUX2) |
| Analogue Outputs |
2 x RCA, 2 x Balanced XLR, 6.3mm Headphone
Jack |
| Speaker Outputs |
1 Pair Speaker Terminals |
| Sample Rate (USB B) |
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz,
192kHz, 384kHz |
| Sample Rate |
44.1 – 192kHz (Digital Inputs / Outputs) |
| Standby Power Consumption |
<0.5W |
| Pre-Amplifier Section |
|
| Output Level (1kHz) Variable Output |
RCA 0-2.3 Vrms / XLR 0-4.6 Vrms |
| Frequency Response |
20Hz-20kHz, 1kHz (± 0.2dB) |
| Total Harmonic Distortion |
< 0.002% (@1KHz, BW=20Hz-20kHz) |
| Signal to Noise Ration(S/N) |
> 110dB (A-weighted, ref. 1V) |
| Channel Separation |
>100dB (1kHz) |
| Power Amplifier Section |
|
| Rated Power Output |
2 x 75W (8Ω) |
| Frequency Response |
± 0.5dB (20Hz-20kHz, 1kHz) |
| Total Harmonic Distortion |
< 0.003% (@1KHz, 50W/8Ω, BW=20Hz-20kHz) |
| Signal to Noise Ration(S/N) |
> 108dB (A-weighted, ref. 75W) |
| Channel Separation |
>82dB (A Weighted, ref.1W) |
| Dynamic Range A-wtd |
>98dB |
| Power Requirement (depending on region) |
220V-240V~50-60Hz
100V-120V~50-60Hz |
| Dimensions & Weight |
|
| Dimensions (Unpacked) |
320 x 320 x 105mm |
| Dimensions (Packed) |
465 x 465 x 220mm |
| Net Weight |
11.5 kg |
| Gross Weight |
13.8 kg |
